DaHua 32 Channel Ultra 4K H.265 Network Video Recorder (NVR) – DHI-NVR608-32-4KS2
DaHua 32 Channel Ultra 4K H.265 Network Video Recorder (NVR) – DHI-NVR608-32-4KS2
Couldn't load pickup availability
Functions
RAID 0/1/5/10
Offering a balance between storage performance, storage capacity, and data integrity, the NVR features Fruitfull RAID 0/1/5/10 for faster and safer recording.
Fisheye Dewarping
The NVR features multiple fisheye dewarping modes to make viewing video easy whether its live or during playback.
N+M Hot Standby
The highly reliable redundancy N+M Hot Standby design provides a secure, failover technique ensuring immediate backup. In the event of a system failure, the slave instantly takes over the master ensuring no data is lost.
4K Resolution
The NVR supports 4K ultra HD resolution (3840 x 2160) for recording, live viewing and playback.
Intelligent Video System (IVS)
With built-in intelligent video analytics, the NVR has the ability to detect and analyze moving objects for improved video surveillance. The NVR provides optional standard intelligence at the edge allowing detection of multiple object behaviors such as abandoned or missing objects. IVS also supports Tripwire analytics, allowing the camera to detect when a pre-determined line has been crossed, People Counting, ideal for business intelligence, and Facial Detection, for searching or identification of individuals.
Heat Map
The NVR’s Heat Map option highlights the areas with the highest concentration of people. This information can then be exported into a customized report to assist in business or forensic analysis.
Point of Sale (POS)
Ideal for grocery and retail stores, the optional POS solution allows the NVR to receive a POS transaction via corresponding video. This feature allows merchants to analyze specific transactions via the Fuzzy search Algorithm.
Smart Tracking
The auto tracking PTZ feature automatically tracks a moving target throughout the camera’s field of view. This function is ideal for following an object as it moves through airports, parking lots, city centres, or other applications.
ANR (Automatic Network Replenishment Technology)
Video record in SD card in IP cameras when the network breaks down, and after the network recovered, the video will be transferred to NVR and then recorded in it.
System
| Main Processor | Intel Dual-core Processor |
| Operating System | Embedded LINUX |
Audio and Video
| IP Camera Input | 32 Channel |
| Two-way Talk | 1 Channel Input, 1 Channel Output, RCA |
Display
| Interface | 2 HDMI (up to 3840 x 2160 , Different Source), 1 VGA |
| Resolution | 3840 × 2160 , 1920 × 1080 , 1280 × 1024,
1280 × 720 , 1024 × 768 |
| Multi-screen Display | 1st Screen: 1/4/8/9/16/25/36 2nd Screen: 1/4/8/9/16 |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
Recording
| Compression | H.265/H.264/MJPEG |
| Resolution | 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP,
720P etc. |
| Record Rate | 384Mbps |
| Bit Rate | 16Kbps ~ 20Mbps Per Channel |
|
Record Mode |
Manual, Schedule (Regular, MD (Motion Detection), Alarm, IVS), Holiday, Stop |
| Record Interval | 1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30
sec, Post-record: 10 ~ 300 sec |
Video Detection and Alarm
| Trigger Events | Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Video Detection | Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering |
| Alarm input | 16 Channel, Low Level Effective, Green Terminal Interface |
| Relay Output | 8 Channel, NO/NC Programmable, Green Terminal Interface |
| Tracking Trigger Event | Zoom, Tracking, Recording, Preset, Snapshot, Alarm, etc. |
Playback and Backup
| Playback | 128 Mbps in Raid 5 Mode; 64 Mbps in single HDD Mode |
| Search Mode | Time /Date, Alarm, MD and Exact Search (accurate to second) |
|
Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
| Backup Mode | USB Device/Network/eSATA Device |
Third-party Support
|
Third-party Support |
Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
Network
| Interface | 2 RJ-45 Ports (10/100/1000Mbps) |
| Ethernet Port | 2 Ethernet Ports Joint Working or 2 Independent 1000Mbps Ethernet Ports |
| PoE | N/A |
|
Network Function |
HTTP, HTTPs, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP,
Alarm Server, IP Search (Support Dahua IP camera, DVR, NVS, etc.) |
| Optical Fiber Interface | N/A |
| Max. User Access | 128 users |
| Smart Phone | iPhone, iPad, Android |
| Interoperability | ONVIF 2.4, CGI Conformant |
Storage
| Internal HDD | 8 SATA III Ports, Up to 8 TB capacity for each HDD |
| HDD Mode | Single, Raid 0/1/5/10(Enterprise-level HDDs are recommended), Support Global HDD Hot-spare |
|
eSATA |
1 eSATA Port (Please contact technical engineer to confirm the compatible device) |
| SAS | N/A |
Auxiliary Interface
| Front Cover | N/A |
| USB | 4 USB Ports (2 USB 2.0 , 2 USB 3.0 ) |
| RS232 | 1 Port, for PC Communication and Keyboard |
| RS485 | 1 Port, for PTZ Control |
Electrical
| Power Supply | AC100V ~ 240V, 50 ~ 60 Hz |
| Power Consumption | <20W (Without HDD) |
Environmental
| Operating Conditions | -10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa |
| Storage Conditions | -20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH |
Construction
|
Dimensions |
2U, 440mm x 451.08mm x 94.85mm (17.3″ x 17.8″ x 3.7″) |
| Net Weight | 9kg (19.8 lb) (without HDD) |
| Gross Weight | 10.5kg (23.1 lb) |
| Installation | Rack-mounted |
|
Certifications
|
Third-party Support |
Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
| Ordering Information | ||
| Type | Part Number | Description |
|
32 Channel NVR |
DHI-NVR608-32- 4KS2 |
32 Channel Ultra 4K H.265 Network Video Recorder |
|
Accessories |
ESS1504C |
4 HDDs eSATA Storage (Please confirm with Technical Support for HDD capacity & compatibility) |
